2-3226-01-20 ［Discontinued］Bimetal Thermometer Sensor shape: T with Calibration Certificate MS-6611
Product Description
Product Model: 2-3226-01-20Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 2-3226-01-20
Product Brand: AS ONE Corporation
Features
- The exterior is made of stainless steel (SUS304) and has excellent corrosion resistance.
- Since it has a sealed structure, it can be ***d outdoors and in chemical plants.
Spec
- Specifications: Calibration Certificate
- Outer diameter: Φ85 mm
- Sensor Shape: T
- Operating temperature range: 0 ~ 100 degrees Celsius
- Minimum scale: 2 degrees
- Material: Stainless steel (SUS 304)
- Mounting screws: PT 1/2
- Accuracy: +/- 2.0%
- Temperature sensitive part size: phi 6.4 x 100 mm
- *"With Calibration Certificate" includes three items at the time of shipment: Calibration Certificate, inspection report and traceability chart.
- *"With Calibration Certificate" is an Azuwan original certificate ancillary service.
- The Calibration Certificate comes with a Japanese version.
- Calibration points are 25 degrees Celsius and 2 points of 80 degrees Celsius. If you would like additional points, please contact us separately.
