Spec

• Model number: ABSZ -1200
• Specifications: Standard
• external dimension (mm): 1200 x 830 x 2250
• inner size (mm): 950 x 605 x 1200
• Weight (About kg): 275
• Exterior: Steel (powder coating finish)
• Interior: chemical resistant Heat-Resistant Board (Flame-Retardant material/phenolic laminated sheet or glass fiber mixed polyester)
• Work Plane: Epoxy Plastic top board Integral Part (32 mm Atsushi)
• Lifting sash: tempered glass (5 mm Atsushi) with balance weight opening restriction key (400 mm Height), Handle: ABS Plastic
• Hydrant: chemical coating Remote Operated Water Connection G 1/2 (Stop Female thread)
• drain port: Plastic Drainage connector 40 A socket with a built-in sink and trap
• Outlet: AC100V -15 A2 grounded
• lighting: Hf fluorescent lamps
• Operating Switch: Touch Panel Lighting/Fan
• Safety Function: Exhaust Air air volume Display
• Exhaust Connections: PVC (Plastic vinyl chloride ) with Volume Damper Phase Flanged
• power supply connection part: Terminal block with electric box
• Jungle: Starchief, Global Muff, Jungle Bar, Center Stability Tower (Round)
• exhaust
• Work Sash Opening Height (mm): 400
• Controlled wind speed (m/s): 0.5
• air volume (m3/min): 12
• Duct Connector: 200 A
• Required duct diameter (Φ mm): 200
• ancillary equipment
• Jungle stick (Vertical x Horizontal): 2 rows x 3 stages
• Plumbing (place): 1
• fluorescent lamps (bottle): 2 x 16 W
• Outlet (place): 2
• *Shipping, carrying-in, installation, assembly, etc. are required separately. Please contact us.
• *Exhaust fan is not included.
