1-7593-01 ［Discontinued］Desktop Vibration Testing Machine CV-101
Product Description
Product Model: 1-7593-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 1-7593-01
Product Brand: AS ONE Corporation
Features
- JIS compliant vibration test can be carried out on the table.
Spec
- Model number: CV-101
- Body
- Vibration frequency: 10 - 300Hz
- Amplitude: 0.2 - 3.0mm (Amplitude goes narrower, as vibration frequency becomes higher)
- Operation mode: Manual mode (Vibration frequency and vibration width are fixed), sweep mode (Automatic sweep JIS compliance)
- Maximum load of the target of measurement: 1kg
- Program for operation hours: Maximum 10 hours (Minimum unit: 1 minute)
- Power supply: 100VAC 50/60Hz
- Power consumption: 200W
- Size: Control box part/152 x 227 x 143mm, Drive part/220 x 150 x 137mm
- Weight: Control box part/1.6kg, Drive part/12kg
- Comply with JIS
