1-5825-11-57 ［Discontinued］Digital Temperature Controller (with program function) - 100 ~ 600°C with with Chinese Calibration Certificate TP-4NK
Product Description
Product Model: 1-5825-11-57Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 1-5825-11-57
Product Brand: AS ONE Corporation
Features
- Temperature control is ON/OFF.
- For the temperature display, the PV/SV two-stage display, which allows you to see the measured value and the set value at a glance, prevents setting errors, etc.
- Up to 8 steps and 4 patterns can be set with the program function.
- Forward and reverse operation can be switched.
- Equipped with circuit protector, alarm output function, and sensor abnormality detection function.
Spec
- Setting temperature: - 100 ~ 600 deg.
- Minimum display unit: 1 deg.
- Temperature display accuracy: +/- 0.5% (FS) +/- 1 digit or 3 degrees Celsius, whichever is greater
- Temperature control method: ON/OFF control
- Temperature setting display: Sheet key touch system, PV, SV digital two-stage display
- Sensor Type: K Thermocouple (phi 4 x 200 mm)
- Connection capacity: 100 VAC 50/60 HazmAX 12 A (resistive load) * Do not directly connect induction load equipment (motor, pump, etc.) to this unit.
- Additional functions: Program functions/8-step 4-pattern
- Safety features: Circuit protector (15 A), alarm output function, sensor malfunction detection
- Power supply: 100 VAC 50/60 Hz
- Body size: 95 x 150.6 x 48.5 mm (excluding protrusions)
- Calibration points are 25 degrees Celsius and 2 points of 80 degrees Celsius. If you would like additional points, please contact us separately.
