1-5481-21-20 ［Discontinued］Digital Multi Temperature Controller With Program Control Function With Calibration Certificate TXN700B
Product Description
Product Model: 1-5481-21-20Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 1-5481-21-20
Product Brand: AS ONE Corporation
Features
- A flagship model that controls temperature gradients.
- It is equipped with a program control function that can store 4 programs of up to 16 steps.
- Creating a program is as simple as setting the temperature and time.
- Temperature and time can be controlled with temperature gradients at different steps.
Spec
- Model number: TXN 700 B
- Temperature settings range: 0 to: 500 ℃
- Power supply : AC100V 50/60Hz
- Timer settable time: 1 to 99 hours 59 minutes
- Connected capacity: AC100V MAX 12 A (resistance load)
- Temperature control method: PID control
- Output control method: voltage output by SSR
- Safety device: current breaker built-in type power supply switch, overshoot prevention mechanism
- Power cord : Approximately 1.8 m (With 3P plug)
- Size: 185 x 210 x 98mm
- Temperature indication accuracy: ±2 ℃ or FS ±0.3% + 1 digit, whichever is larger
- Timer Type: Programmable
- Sensor Type: K thermocouple
- Program Settings: Up to 16 steps (4Memory of Type available)
- *The sensor is sold separately.
- *Only for K class thermocouple.
- Accessories: Calibration certificates
- *Products with calibration certificate is a service where equipment is calibrated and calibration certificate is issued at the time of shipment.
