1-4598-01 ［Discontinued］Digital Overtemperature Control Device OP-1000
Product Description
Product Model: 1-4598-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 1-4598-01
Product Brand: AS ONE Corporation
Features
- Power is automatically turned off when the temperature exceeds the set temperature (power is turned on again for reset).
- Uses a jog dial system for quick and reliable temperature setting.
- The display screen is a backlit liquid crystal screen with excellent visibility and displays both the set temperature and the measured temperature simultaneously.
Spec
- Model number: OP-1000
- Settings range: -20.0 - 500.0℃
- Minimum display unit: 0.1℃
- Temperature display precision: To +/-2.6℃
- Sensor: K class thermocouple
- Connection capacity: AC100V MAX12A
- Safety device: Sensor abnormality detection, circuit protector
- Temperature setting system: LCD digital display (setting/measurement temperature simultaneous display)
- Additional function: Settings memory, key lock function
- Power supply: 100VAC 50/60Hz
- Size: 147 x 150 x 106mm
- Accessories: K class thermocouple x 1
- *It doesn't return when temperature goes down after the power is cut by the temperature excessive rise.
