1-2995-01-20 ［Discontinued］OverTemperature Control Device, Alarm Generator With Calibration Certificate AL-3A
Product Description
Product Model: 1-2995-01-20Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 1-2995-01-20
Product Brand: AS ONE Corporation
Features
- If the temperature exceeds the set temperature, the power is turned off and does not return even after the temperature has decreased (temperature rise prevention function).
- Turns on a separately connected alarm or lamp according to the set temperature (alarm generation function).
- Can be hung on a device or wall for compact ***.
- With round terminal type temperature sensor that is easy to fix to the object.
Spec
- Model number: AL -3 A
- Setting range: 0 to 999 ℃ (The temperature of the attached sensor is 200 ℃, so the default setting range is 0 to 200 ℃. You can change the setting range according to your sensor specifications.)
- Minimum display unit: 1 ℃
- Display accuracy: ±0.5% rdg ±1 dgt or ±3 ℃ (Sensor error not included)
- Operation: Lamp ON/internal relay ON/OFF (Switchable)
- Temperature sensor: K-type thermocouple
- Output method: Voltage output by relay contact
- Output rating: AC100V 50/60Hz MAX 12 A (resistance load)
- Safety function: 15 A capacity Circuit Breaker Sensor Burnout circuit on disconnection
- Size: 95 x 150 x 47mm (not including protrusions)
- Power cord length: 2.0 m (3P plug)
- Accessories: Round terminal sensor (K class thermocouple)
- *Do not connect the induction load device (Motor pumps, etc.) directly to the tester.
- Accessories: Calibration certificates
- *Products with calibration certificate is a service where equipment is calibrated and calibration certificate is issued at the time of shipment.
