1-5504-83 ［Discontinued］【Global Model】 Auto Dry Desiccator 574 x 524 x 1135mm Reinforced Plastic Shelf Board Single-Phase 230V±10% SP-BGKFN-PG
Product Description
Product Model: 1-5504-83Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 1-5504-83
Product Brand: AS ONE Corporation
Features
- The dead space in the desiccator is eliminated, and the inside of the cabinet can be ***d effectively.
- By adopting a new type of door opening/closing mechanism and eliminating dead space when opening/closing the door, it can be installed without clearance on the wall surface.
- The new dehumidification unit has no driving part and no source of sound or vibration, so it has excellent durability.
- Moisture inside the desiccator is released directly to the outside in a gaseous state, so water droplets (drains) do not appear.
- Comes with casters for easy movement.
- The humidity control is controlled (analog setting) on the front panel.
- Standard series of lightweight aluminum frame and resin clear panel.
- A new type of solid polymer electrolyte membrane (Rosal) is installed on the front panel to directly electrolyse and continuously remove moisture from the interior air, enabling stable dehumidification.
Spec
- Auto Dry Type
- Humidity setting range: 20 to 50 %RH (It dep***s on environment ***d.)
- Humidity control range: 20 %RH to room humidity (In environment ***d at the time of unload)
- Humidity control system: Automatic dial adjustment (early leaving humidity)
- material (Body / Frame): PMMA (acrylic) / aluminum
- Caster specification (front wheel 2 locations stopper): Made from 65 mm (nylon)
- shelf board specifications: reinforced plastic
- shelf board Dimensions / Mounted pitch: 490 x 460 mm / 50 mm
- shelf board interval : 35 mm
- shelf board Load tolerance: about 10 kg / sheet
- power supply: Single-Phase 230V±10%
- Average Power Consumption: 4W
- Maximum Power Consumption: 27 W
- Weight: 21 kg
- Accessories: shelf board x 4 pieces, high precision digital temperature humidity indicator (THI-HP)
- external dimension (mm): 574 x 524 x 1135
- inner size (mm): 560 x 483 x 864
- Reinforced plastic shelves and casters
- Model Number: SP-BGKFN-P
- Country of origin: Japan
- Control Panel : English
- Plug: Type I (https://en.wikipedia.org/wiki/Mains_electricity_by_country)
*This product might require extra fees.
