3-4745-01 Force Tester (General-Purpose Type) MCT-1150
model:
3-4745-01
category:
toner
Product Description
Product Model: 3-4745-01 Features Color touch panel pro […]
Contact Us
Product Details
Product Model: 3-4745-01
Features
- Color touch panel provides good visibility and easy operation.
- Beca*** of its space-saving design, it can be ***d on a desktop and does not require load cell calibration.
- It calibrates automatically when the power is turned on and can be tested immediately.
- PC capture software is included as standard.
Spec
- Model number: MCT-1150
- Specification: Body (general-purpose type)
- Maximum load capacity: 500N
- Crosshead stroke: 400mm
- Effective stroke: 315mm
- Crosshead speed range: 10 - 300mm/min, ±5% of settings
- Load measurement accuracy: 500N - 50N: ±0.2%F.S 50N - 5N: ±2% of the indicated value, 5N or less: Within ±0.1N
- Supported OS: Windows(R)Vista(R)/7(32bit)
- Power supply: AC90 - 240V 50/60Hz
- Power consumption: 90W
- Accessories: Software for importing to PC
- Contents of attachment set: Hook (JM-X002-500N), V-groove indenter (JM-X003-500N), Pressure receiving plate φ15mm (JM-X004-500N), Conical indenter (JM-X005-500N), Mountain-shaped indenter (JM-X006-500N), Extension rod (JM-X007-500N)
