1-5309-12 High Precision Radiation Thermometer (Narrow Field Type) IT-545N
model:
1-5309-12
category:
toner
Product Description
Product Model: 1-5309-12 Features Adopting a unique str […]
Contact Us
Product Details
Product Model: 1-5309-12
Features
- Adopting a unique structure that is resistant to changes in environmental temperature, it provides excellent stability in measured values and greatly reduces drift.
- Measures the temperature of a circular area with two laser markers as its diameter.
Spec
- Measurement range (℃): -50 to +500
- Resolution (℃): -50 - 0/1, 0.0 - 199.9/0.1, 200 - 500/1
- Accuracy: - 50 - 0℃/±(5% rdg + 1.5) ℃ or lower, 0.0 - 199.9℃/±1.0℃ or lower, 200 - 500℃/±(0.5% rdg + 0.5) ℃ or lower
- Reproducibility: ±1℃ or lower (-50 - 0℃ ), ±0.3℃ or lower (0.0 - 199.9℃), 1℃ or lower (200 - 500℃)
- Emissivity: 0.10 - 1.00 (0.01 steps)
- Distance factor (D: S) : 12.5: 1
- Response time: 0.8 seconds or less
- Function: Maximum/minimum value display, Hold, Laser marker (2 points)
- Other function, accessories: Auto power OFF
- Power supply: AAA dry cell x 4
- Size (mm): 40 x 170 x 36
- Weight (g): 140
- Model number: IT-545N
