68-1816-66 546x352x142mm/18.9 L Container EA506AL-58
model:
68-1816-66
category:
gasmonitors
Product Description
Product Model: 68-1816-66 Features Stackable It is a ty […]
Contact Us
Product Details
Product Model: 68-1816-66
Features
- Stackable
- It is a type adopted in a stacking 2 color container (SN container) with the same color by 180° rotation. It is also called the same color and shape stacking type. By rotating the product 180° horizontally, two forms of stacking and nesting can be achieved. When stacking, it can be ***d for transporting and storing products. By nesting when empty boxes are ***d, the volume can be reduced and the storage location and transportation cost of empty boxes can be reduced. Designed with emphasis on load-bearing capacity during stacking, it has excellent strength during stacking. Compression Load in the Product Detail Specification (indicates the maximum compression load for the stacked product. Divide the value by 4 as a guideline).
- 1100 x 1100 modules (6 mounted)
- With label peeling rib in front of side
Spec
- Manufacturer: Sanko
- Model number: 201989
- Product Name: SN Container B#19 T
- Capacity: 18.9 L
- External Dimensions (mm): 546 x 352 x 142 (H)
- Color: Blue/Light Blue
- Inner Dimensions (mm): 496 x 306 x 130 (H)
- Effective Inner Dimensions: 480 x 290 x 119 mm
- Compression load: 12.94 kN (1320kgf)
- Material: Polypropylene
- Weight (g): 1480
- Bottom Shape: Grid Rib A grid rib (a plate shape erected perp***icular to the plane to reinforce the plane) is installed on the bottom surface. The rib height determines the b***ing strength, and the higher the rib, the higher the strength. It is often ***d in industrial containers, especially in industries that *** oil, and it has the effect of suppressing deflection due to swelling (a phenomenon in which resin absorbs oil, etc., and the volume increases).
- Nesting height: 72 mm
