69-3932-06 φ100 Pressure Gauge JIS Compatible Sealed Pressure Gauge BE15 General G3/8B D Frame (Mounting Hole) BE15-231-0.1-0.16MPA
Product Description
Product Model: 69-3932-06Product Brand: NAGANO KEIKI Co […]
Contact Us
Product Details
Product Model: 69-3932-06
Product Brand: NAGANO KEIKI Co., Ltd.
Features
- Compatible with JIS B 7505-1:2007 Bourdon tube pressure gauge.
- A pressure gauge with a structure that transmits the elastic deformation (movement) of Bourdon tube pressure to the needle. The simple structure makes handling easy.
- It can measure in a wide pressure range and is ***d in a wide range of fields.
- The *** of a sealed case allows it to be ***d under conditions such as rain and fog. (Equivalent to JIS C 0920 IP 43)
- Standard conformity certification (type approval) is possible.
- The pressure setting range is wide and corrosion resistance is required.
Spec
- Type: Sealed pressure gauge
- Size: φ100
- Pressure range: -0.1~0.16 MPa
- Model: Recessed Metal Case
- Shape: D Frame (Mounting Hole)
- Connecting Screws: G3/8B
- Use: General ***
