Electronic/Electrical Parts and Controll Equipments
63-4746-89 Philips Technologies NC 1 A Bi-Metallic Thermostat, Opens at+100°C 67L100
model:
63-4746-89
brand:
Philips Technologies
Product Description
Product Model: 63-4746-89Product Brand: Philips Technol […]
Contact Us
Product Details
Product Model: 63-4746-89
Product Brand: Philips Technologies
Features
- T0220 Thermostats. Miniature bimetallic thermostats TO-220 Housing Normally open and normally closed versions are available Tolerance ±5°C Resistance: 20mΩ 100000 cycles @ 5Vdc/20mA 38000 cycles @ 48Vdc/1A Dimension between leads: 5.08mm
Spec
- Quantity：1piece
- Minimum Temperature : +40°C
- Maximum Temperature : +130°C
- Opening Temperature : +100°C
- Thermostat Type : Bi-Metallic
- Switch Configuration : NC
- Contact Rating : 1 A
- Contact Voltage Rating : 48 V dc, 120 V ac
- Terminal Type : PCB Pin
- Mounting Type : PCB Mount
- CODE No.:253-2773
