1-3889-18 Stabilized DC Power Supply Wide Range PSW-1080L80
Product Description
Product Model: 1-3889-18Product Brand: TEXIO TECHNOLOGY […]
Contact Us
Product Details
Product Model: 1-3889-18
Product Brand: TEXIO TECHNOLOGY
Features
- A switching type DC stabilized power supply that can provide a wide range of voltage and current outputs within the maximum rated power.
- A total of 15 models of 3 types with output capacities of 360 W/720 W/1080 W and 5 types with maximum voltages of 30 V/80 V/160 V/250 V/800 V are available for a wide range of applications.
- USB and LAN ports are provided as standard, and it can be installed in a rack, so it can be ***d for system power.
- It also supports CE marking and the European RoHS Directive.
Spec
- Model number: PSW-1080L80
- Size (mm): 214 x 350 x 124
- Output (current/voltage) rated power: 0 - 80V/0 - 40.5A/1080W
- Display and output range: Set resolution: Voltage 10mV/current 10mA/power 10W (wider range voltage settings at the rated power range, Current settings available)
- Various function: Test mode, Output through-rate setting, Internal resistance variable available capacity, CC/CV priority mode, Bleeder circuit ON/OFF
- Master slave operation: Parallel connection/the same model 3 units, Series connection (250V, Except for 800V model)/the same model 2 units
- Interface: External analog control, LAN (Ethernet) port, USB host/device port, GP-IB (option)/GUG-001 (GP-IB-USB converter)
- Power voltage: AC100 - 240V/50 - 60Hz worldwide correspondence (however standard included power cord AC100V only)
