1-2123-01 ［Discontinued］Cooling Water Circulator LTCi-150H
model:
1-2123-01
category:
laboratoryinstruments
Product Description
Product Model: 1-2123-01 Features Ultra-compact inverte […]
Contact Us
Product Details
Product Model: 1-2123-01
Features
- Ultra-compact inverter control for energy saving
- Compact size with ultra-compact compressor.
- An energy-saving type with an inverter controlled compressor.
- You can check the amount of water from the transparent window of the cooling tank.
Spec
- Heater: Is available
- Temperature settings range (℃): 2 - 60
- Built-in pump: Standard
- Circulation method: Sealed system circulation
- Temperature control accuracy: +/- 0.05 to +/- 0.1℃
- Temperature control system: PID control
- Type of liquid ***d: Water, ethylene glycol water solution, ethanol water solution
- Circulation pump (no load): Maximum flow rate 1.5L/min, maximum head 3.0m
- Heater capacity: 300W
- Cooling capacity/refrigerant: 150W (at 25℃)/R134a
- Safety mechanism F***, float switch
- Power supply: 100VAC 50/60Hz maximum 5A
- Power cord length: About 1.8m (3P plug)
- Material: Body/steel melamine bake coating, Cooling coil/Copper tube nickel plating
- Tank capacity: Reservoir tank 0.4L
- Circulation nozzle: Outer diameter φ11mm (adaptive tube inner diameter φ9mm)
- External dimensions: 140 x 280 x 313mm (not including projections)
- Weight: Approx 8kg
- Accessories: Hose 1m (Inner diameter φ9mm) x 2 pieces
- Model number: LTCi-150H
- *You can get value in performance when room temperature is 25℃, using the rated current voltage with no load.
