Spec

• Size: 68 x 201 x 42 mm
• Weight: 350 g (including battery)
• Accessories: Instruction Manual, Certificate of Tests, Warranty, Soft Case, Simple Tools, AA Alkaline Batteries (LR6) x 4, ACAP4 (1 box of printer paper)
• Display: 7-segment LCD (liquid crystal)
• Operation switch: Membrane switch
• Input Connector: ASP Connector (Thermocouple Homogeneous Metal)
• Thermocouple Type: E Type
• Number of input points: 1
• Measurement Range: 1°C Decomposition/-200~800°C, 0.1°C Decomposition/-104.9~504.9°C (outside the measurement range, automatic switching to 5°C decomposition)
• Measurement accuracy: 1°C decomposition/0°C or more ...± (0.1% of the indicated value +1°C)
• Accuracy of reference contact compensation: ±0.2°C (in a 25°C±10°C environment)
• Temperature coefficient: ± (0.01%/°C) of measurement range
• Signal Source Resistance (Ω): 500 or Less
• Operating conditions: 0~40°C, 0~80%RH or less (no condensation)
• Storage Conditions: -20~50°C, 0~85%RH or Less (No Condensation)
• Time in Use (unit/hour): 150
• Power supply (internal): AA alkaline battery (LR6) x 4
• Power Supply (External): AC Adapter (Sold Separately)
• Internal battery: Lithium battery (for watch backup)
• Battery Life: Approximately 5 years (at room temperature)
• Printing Part: Character Height 2.5 mm (1 Roll Prints Approximately 1000 Lines)
• Printing System: Thermal Serial Dot System
• Memory Capacity: 100 Data
• Compliance standard: RoHS Directive (as of January 2023)
