3-6775-01-22 ［Discontinued］Power Stirrer (for Oil Bath) with Pre-shipment Inspection Certificate VPS-200SOB
Product Description
Product Model: 3-6775-01-22Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 3-6775-01-22
Product Brand: AS ONE Corporation
Features
- Since a shielding plate is provided on the stainless steel top plate, it is possible to stir while keeping the oil bath on top.
- Uses a strong magnet and induction motor for high viscosity and high volume stirring.
- Feedback control by the taco generator allows stable rotation from low speed to high speed.
- Achieves stable rotation even in the low rotation range.
- You can *** the analog knob to set the number of revolutions relative to the scale.
- A special metal fitting can be attached to the back, and can be ***d as a stand when combined with a support rod.
Spec
- Material: Body/SPCC (acrylic paint), Top plate/Stainless steel (SUS 304)
- Motor: Induction motor
- Variable speed system: Feedback control by taco generator
- Load capacity: 22 kg
- Top size: 200 x 200 mm
- Speed: 60 ~ 1350 rpm
- Motor: 15 W
- Stirring capacity: 20 L
- Magnet/Strength (T): Samakoba/0.37
- Power supply: 100 VAC 50/60 Hz, 2.5 m 3 P plug
- Maximum power consumption: 40 W
- Body size: 200 x 200 (211) x 152 mm (() includes projections)
- *Stirring capacity and number of revolutions are for water.
- Weight: 5.0 kg
- *The size of the stirrer ***d dep***s on its capacity and viscosity. Use them according to your purpose.
- Inspection contents App***ix: Inspection inspection documents
- Actual speed, insulation resistance value and apPearance
- App***ix: Inspection Certificate documents
- *Products with Inspection Certificate are Azwan's original service that includes inspection of control and electric engine personnel and issuance of inspection documents at the time of shipment.
