Spec

• Product Type: Inkjet printer MFP
• Product Family: imagePROGRAF
• Specifications: [Basic]
• Print Head (Number of Nozzles): MBKx5, 120 nozzles, BK/C/M/Y x 2 each, 560 nozzles, total 15, 360 nozzles
• Maximum resolution: 2400x1200dpi [ink tank]
• Volume: 160 ml/330 ml/700 ml for each color (can be mixed. The initial included ink is MBK: 330 ml, BK/C/M/Y: 160 ml)
• Supply Method: Tubing Method (With Sub-ink Tank/Can Replace Ink During Printing)
• Paper source: Manual feed (cut paper), Roll paper (Double roll paper can be fed when the option is installed) [Supported paper length]
• Roll Paper: Minimum 101.6 mm to Maximum 18 m
• Cut Paper: Minimum 203 mm~ Maximum 1, 600 mm (When Mounted with Stand)
• Applicable Paper Width: Minimum 152.4 mm to Maximum 610 mm (24inch/A1 Novi)
• Roll Paper Maximum Outer Diameter: 170 mm
• Paper thickness: Manual feed (cut/top) 0.07~0.8 mm, Roll paper 0.07~0.8 mm [Interface]
• USB:Hi-Speed USB
• Wired LAN: 10Base-T, 100Base-TX, 1000Base-T
• wireless LAN: IEEE802.11n/g/b
• Distance accuracy: ±0.1%
• Printer languages: SG Raster, HP-GL/2, HP RTL, PDF (PDF compliant with V 1.7), JPEG (JFIF1.02 compliant)
• Internal memory: 128GB
• Hard disk: 500GB encrypted
• Power: 100 VAC (50/60Hz)
• Power consumption: 87 W or less during operation, 2.0 W or less during sleep
• Operating noise: Approximately 50dB (A) or less during operation, and approximately 35dB (A) or less during standby
• Operating environment: Temperature 15~30°C, Humidity 10~80% (non-condensing)
• Dimensions (WxDxH); Basket Closed: 1, 189x766x1, 422 mm
• Body Weight: Approx. 111 kg
• Related standards: VCCI Class B information processor, International Energy Star Program, Law on Promoting Green Purchasing, Eco Mark
• Specifications 2: [Scanner]
• Scanner System: CIS System (Sheet Through Type)/Single Sensor Technology
• Optical resolution: 1200dpi [scanned document]
• Scanning Width: 158~610 mm
• Media Width: 158~660 mm
• Media thickness: 0.07~1.0 mm
• Document feed/output method: Front feed, paper output can be selected from front or back.
• Accuracy: ±0.1% [scan speed]
• Color: 152.4 mm/sec (color copy (draft) 200dpi)
• Monochrome: 330.2 mm/sec
• Interface: Scanner: USB3.0, Controller: USB2.0, USB3.1, 100/1000Base-TX
• Control Panel: 15.6 inch color LCD touch panel monitor
• Scan & Copy System: SmartWorks MFP [controller]
• Memory: 8GB
• Storage: 250GB (SSD)
• Dimensions Width x Depth x Height (mm) (without return guide): 751x251x156mm
• Weight: 5.8 kg
• Power: 100~240 VAC 50/60Hz [Power consumption]
• Scanner Body: Operating: 23.3 W or Less, Sleep: 0.2 W or Less
• Controller/Monitor: Operating: 50.1 W or less, Sleep: 1.7 W or less
• Maximum scan length: 15.24 m(All-color mode, TIFF format/~200dpi)
• Color Mode: Color/Grayscale/Black/White Binary
• Saved file formats: PDF (single/multiple), PDF/A, TIFF, JPEG, DWF
• Scan destination: Local folder (including shared folder), USB flash drive, Cloud linkage, Windows shared folder, FTP
• Scanning USB Flash Drive: USB3.0
• Paper Alignment: Center [Copy]
• Supported paper: TX series compatible paper (linked to printer paper settings)
• Maximum copy length: 15.24 m (at ~200 dpi)
• Scan (save file) and copy at the same time: Yes
• Scaled copy: Can be specified in increments of 1 ~ 500% and 1%
• Code number: CA108EM
