Spec

• Lighting and light receiving conditions
• Reflection/8°: de (8° illumination: diff*** light reception)
• Transmission/0°: d (i Diff*** illumination: 0° light reception)
• Light Source: Wide Area White LED Measuring Diameter (Open Diameter): Reflection/LAVφ22 mm (φ28 mm)/MAVφ6 mm (φ10 mm)/SAVφ4 mm (φ6 mm)
• Measurement accuracy: 30 measurements at 15 second intervals on a standard white plate after the lapse of a stable time
• Color difference (∂ E*ab): within 0.03 standard deviations
• Observation conditions/observation light sources: A, C, D65,F6,F8,F10/2° and 10° for each light source
• Visual field measurement items color system: XYZ, Yxy, L*a*b*, L*C*h*, Lab, HVC, etc.
• Index: Y (IE313-05), Y (ID1925), W (CIE), WB, etc.
• Color difference formula: △ E*ab, △ E, △ E*94, △ E00, etc.
• Power voltage: AC100-240V
• Size: W425 x D350 x H188mm
• Weight: approx. 8 kg
• Optional: Dedicated printer (dot type), color management software, various attachments
