Spec

• Model number: ED -2 (With pre-shipment inspection certificate)
• Outer dimensions (mm): 520 x 390 x 325
• tank inner size (mm): 480 x 350 x 150
• Material : water tank/Stainless steel (SUS304) (Insulation In) , Controller unit exterior/Stainless steel (SUS304) , water tank cover/Hard PVC (vinyl chloride Plastic)
• Temperature settings range : R.T. + 5 to 60 °C (MAX 70 °C)
• Temperature control accuracy: ±1 °C (Performance of the controller alone)
• Temperature controller: PID control
• Stirring in chamber: Jet stirring method
• Heater capacity: 1 kW
• Main Weight: about 12kg
• Power supply: AC100V 50/60Hz 11 A
• Safety equipment: Prevention of excessive temperature rise and prevention of float type dry firing
• *The pre-shipment inspection certificate is included.
