1-2123-03 ［Discontinued］Cooling Water Circulator with Heater LTCi-150HP
Product Description
Product Model: 1-2123-03Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 1-2123-03
Product Brand: AS ONE Corporation
Features
- Ultra-compact inverter control enables energy saving.
- Compact size with ultra-compact compressor.
- An energy-saving type with an inverter controlled compressor.
- You can check the amount of water from the transparent window of the cooling tank.
Spec
- Model number: LTCi-150HP
- Circulation method: Sealed system circulation
- Temperature control accuracy: +/- 0.5℃
- Temperature control system: PID control
- Type of liquid ***d: Water, ethylene glycol water solution, ethanol water solution
- Circulation pump (no load): Maximum flow 3.5L/min, maximum head 4.0m
- Heater capacity: 300W
- Refrigerant: R134a
- Safety mechanism Temperature f***, float switch
- Power supply: 100VAC 50/60Hz maximum 5A
- Power cord length: About 1.8m (3P plug)
- Material: Body/steel (Melamine bake coating), Cooling coil/copper tube nickel plating processing
- Tank capacity: Reservoir tank 0.4L
- Circulation nozzle: Outer diameter φ11mm (adaptive tube inner diameter φ9mm)
- External dimensions: 140 x 280 x 313mm (not including projections)
- Weight: Approx 8kg
- Accessories: Hose 1m (Inner diameter φ9mm) x 2 pieces
- Heater: Is available
- Built-in pump: High power
- Temperature adjustment range (℃): 2 - 60
- Cooling capacity: 150W (at 25℃)
- *You can get value in performance when room temperature is 25℃, using the rated current voltage with no load.
