Spec

• Model: With Alarm Function
• Measurement Method: Lithium Ion Solid Electrolyte Method
• Transmission signal: 1~5 V DC
• Measuring range: 0.01~10.00%
• Response time: 120 seconds or less (90% response)
• Measurement value display: 4 digits (digital display with red LED)
• Resolution: 0.01% (less than 1.0%)/0.1% (more than 1.0%)
• Accuracy rating: < 1.0%/±10%±0.01% of measured value, ≥ 1.0%/±10%±0.1% of measured value
• Reproducibility: +/- 2% of measured value
• Temperature dep***ence: +/- 3% of measured value
• Barometric pressure dep***ence: 0.1% of measured value/hPa
• Load resistance: 1 MΩ or more
• Warm-up time: About 30 minutes
• Correction: 1-point correction of inspection gas by special inspection kit (sold separately)
• Operating Temperature/Humidity Range: 0~45°C/0~95%RH (No Condensation)
• Power: 100 VAC ±10%, 50/60Hz
• Power Consumption: Approx. 8VA
• Alarm settings
• One upper limit and one lower limit are set arbitrarily (Back cover key operation).
• Setting range (step): 0.01~10.00% (0.01%)
• Optional selection of upper/lower limit alarm operation
• With/without buzzer sound output is optional (both upper and lower limits).
• Alarm output
• Upper/lower limit individual LED lights on
• Relay Contact Output: One Upper/Lower Circuit a Contact
• Contact Capacity: Resistance Load (110 V AC, 0.2 A/24 V DC, 1 A), Induction Load (110 V AC, 0.1 A/24 V DC, 0.5 A)
• Device abnormality: Error display when device abnormality or heater disconnection, upper and lower limit LED lamp lights up, upper and lower limit relay output
• ISO 14001 Certified JQA-EM2414
• ISO 9001 Certification JQA-0656
