Spec

• Measurement Range: -40~300°C
• Measuring Diameter/Measuring Distance: φ45 mm/500 mm
• Accuracy rating: ±1%±1digit of the measured value or ±2°C±1digit, whichever is greater.
• +/-30~0.1 degrees C・・・±3 degrees C±1digit, ≤ -30 degrees C ・・・±5 degrees C±1digit(At an ambient temperature of 25 degrees C±2 degrees C and an emissivity epsilon =1.0)
• Reproducibility: within 1°C±1digit
• Responsiveness: 1 second (90% response)
• Measurement position confirmation: Indication of center by laser beam
• Laser beam power: 1 mW or less (650 nm), JIS Class 2
• Display: Reflective LCD Display, 3 Digits
• Display resolution: 0.5°C, except 1°C below -20°C and above 100°C
• Auto Power Off: Power off after about 3 minutes without any key operation
• Communication specifications: Bluetooth® version 4.1 or later
• communication protocol: dedicated UUID
• emissivity setting
• Factory default: 0.95
• Variable between 0.8~1.0 with internal switch (0.05 steps)
• Operating Temperature Range: 0~50°C
• Operating humidity range: 90%RH or less (no condensation)
• Storage temperature: – 20~55°C
• Power: 2 x AAA alkaline batteries
• Battery life: Approximately 10 hours of continuous ***
• External Dimensions: W59.6 x H119.6 x D54mm
• Case Material: ABS Resin (Antibacterial Specification)
• Weight: Approx. 123 g (including batteries)
• Accessories: 2 alkaline AAA batteries, strap, instruction manual
• App (free download)
• Supported OSes: AndroidOS 5.0 or later, iOS 11 or later
• Number of simultaneous connections: Up to 2
• Measurement value transfer: Switch operation (during HOLD)
• Data display: equipment code (format), data, serial number, measurer
• Measurement mode: (1) Switch operation, (2) 1 Data deletion function/Deletion of latest loaded data is possible.
• saving files: saving data in csv format
• safety standard
• Consumer Product Safety Law Certified Standard: Portable Laser Application Equipment (PS/C Mark)
• Protective Structure: IP67 Dust-Proof Waterproof Structure
• Shock resistance: normal operation after falling from a height of 1 m onto a vinyl tile floor
• Traceability certificate *, transcript (sold separately)
• *Certificate breakdown: certificate body, traceability diagram, specification of standard instrument, copy of standard instrument report
