4-2732-01 ［Discontinued］Cooling Water Circulation Device -15 to + 30 ° C SOC-700
Product Description
Product Model: 4-2732-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-2732-01
Product Brand: AS ONE Corporation
Features
- It has a touch screen that is easy to see and operate.
- Various alarm functions are provided.
- Equipped with hot gas bypass control to improve temperature control accuracy.
- It is equipped with a drain drain for easy drainage of condensation water.
- The front filter mounting plate is fixed with a magnet, so it can be easily removed.
- The operation section has an angle of 45 degrees and is easy to see and operate when placed on the floor or on the table.
- Optimum cooling device for rotary evaporator
Spec
- Cooling/circulation system: Air cooling/circulation to closed system
- Liquid Type: tap water, Ethylene Glycol, etc.
- temperature settings range : − 15 to + 30 ° C (No Heater)
- Temperature Adjustment Accuracy: ± 1.0 ° C
- Cooling ability (at 25 degrees C): 10 ° C, About 460 W/at Liquid Temperature - 10 ° C, About 110 W
- maximum flow rate: about 12 L
- Maximum lifting height: Approximately 8 m
- temperature control: hot gas bypass control
- Temperature Setting/Display: Touch Screen Input/Digital Display, Minimum Digit 0.1 ° C
- Safety Function: Leakage/Overcurrent Breaker, Delay Timer for Refrigerator Protection, Water Level Sensor, Refrigerator Overload Relay Protection Function, Temperature Upper/Lower Limit Alarm Function
- External Input/Output: None
- Refrigerator/Refrigerant: Air Cooled 360 W/R -134 a
- Heat Exchanger: SUS316L, SUS304 Brazing Plate Heat Exchanger
- External Circulation Nozzle: Metal Nozzle/outer diameter 10 mm (Compatible Tube inner diameter Φ8 to 9 mm)
- water tank material : SUS304 , 236 x 150 x 143 mm , Approx . 5.0 L (Liquid Amount: Approximately 4.2 L)
- Dimensions : 212 x 482 x 637 mm
- Operating ambient temperature range: 5 to 35 ° C
- Mass: 30 kg
- power supply Voltage: AC100V 50/60 Hz
- *R.T. 20 ° C/Maximum Circulation/power supply AC100V 60Hz ability Value without Load.
