2-935-01 ［Discontinued］Constant-Low-Temperature Circulating Water Circulator 250W LBX-300
Product Description
Product Model: 2-935-01Product Brand: AS ONE Corporatio […]
Contact Us
Product Details
Product Model: 2-935-01
Product Brand: AS ONE Corporation
Features
- Next generation standard model with full basic performance.
- Excellent temperature control accuracy with temperature stability of ±0.05°C or less.
- Can be ***d as a cooling water circulation device for external sealed systems.
- It has a wide operating temperature range and can be ***d for a wide range of experiments and reactions.
- High temperature protection, liquid level protection and circulating pump motor lock/high temperature protection in accordance with IEC61010-01 and IEC61010-2-010.
- Uses bright and highly visible LEDs.
- The front grill can be removed without using tools, so maintenance is easy.
- Since the operation part is located above the water tank, it is difficult to leak water, and there is no concern when taking the sample in or out.
- Robust and soft design reduces pressure when installed on the laboratory table.
- Uses a flat water tank with no irregularities, making it convenient for putting in and taking out work.
Spec
- Temperature settings range: -25 to +95℃
- Temperature stability: +/- 0.05℃
- Temperature distribution: +/- 0.5℃
- Cooling capacity (@20℃, Water temperature 20℃): 250W
- Flow rate (50/60Hz): 12/15L/min
- Discharge pressure (50/60Hz): 200/250mbar
- Water tank dimensions (mm): 170 x 350 x 190
- Opening dimensions (mm): 167 x 188
- Outer dimension (mm): 260 x 455 x 665
- Water level: 160mm
- Water tank capacity (L): 9.5
- Safety device: High temperature, low temperature alarm, No-water burning prevention device, Pump lock protection device, Sensor failure detection apparatus, Overcurrent protection
- Timer function: Auto start/stop
- Program function: 6 steps (maximum 99 times repeat)
- Circulating nozzle (connection port) φ12.7mm, Stainless steel (SUS304)
- Refrigerant: R134a
- Material: Water tank/Stainless steel (SUS304), Heater, cooling coil/stainless steel (SUS316L), Body/Steel powder baking coating finish
- Heater capacity: 1000W
- Power supply: 100VAC 50/60Hz 15A
- Power cord: 2.5m, 3P plug
- Weight: 35kg
- Accessories: Cover
- *Demonstration equipment -02 is available.
- Model number: LBX-300
