65-4329-78-20 Pressure transmitter analog output 4~20 mA DC 100 kPa with inspection certificate KP15-17G
Product Description
Product Model: 65-4329-78-20Product Brand: NAGANO KEIKI […]
Contact Us
Product Details
Product Model: 65-4329-78-20
Product Brand: NAGANO KEIKI Co., Ltd.
Features
- The KP15 is a diaphragm type transmitter that ***s SUS316L material for the diaphragm. Beca*** it is stainless welded, it can be ***d for a wide range of media, and is ***ful in various industries where low pressure and absolute pressure measurement are required.
Spec
- Shape (Mounting): Connector Type M12 Connector (4 Pole) External Adjustment Type Cable Sold Separately
- Connection: R1/4
- Material/Seal Method: Diaphragm: SUS316L Joint: SUS316L
- Pressure Range: kPa_0~100
- Accuracy: ±0.25%F.S.
- Power: 9~36 V DC
- Output: 4~20 mA DC (2 wire)
- Treatment: No oil, no water
