Spec

• Maximum Resolution: Category 6A/6
• 4K(4096×2160)60Hz(4:2:0)100m
• 4K(4096×2160)30Hz(4:4:4)100m
• 4K(3840×2160)60Hz(4:2:0)100m
• 4K(3840×2160)30Hz(4:4:4)100m
• 1080P (1920 x 1080) 100 m * In long reach mode/150 m
• Category 5e/5
• 4K(4096×2160)60Hz(4:2:0)90m
• 4K(4096×2160)30Hz(4:4:4)90m
• 4K(3840×2160)60Hz(4:2:0)90m
• 4K(3840×2160)30Hz(4:4:4)90m
• 1080P (1920 x 1080) 100 m * In long reach mode/150 m
• *This product communicates between devices (LAN communication) via an ext***er without converting Ethernet signals.
• *Use of a good quality Cat6 or better LAN cable is recomm***ed when using the long reach mode.
• Interface: [Transmitter]
• HDMI Type A (19pin) female x 1
• USB B connector female x 1
• RJ-45 female x 2
• 2 3.5 mm stereo mini jacks
• [Receiver]
• HDMI Type A (19pin) female x 1
• USB A connector female ×3
• RJ-45 female x 2
• 2 3.5 mm stereo mini jacks
• Transmission distance: 100 m
• *Up to 150 m when using long reach mode
• Supported LAN cables: CAT6A straight, CAT6 straight, CAT5e straight, CAT5 straight
• *Cable standards and ext***able distance differ dep***ing on the resolution.
• Bandwidth: Single-link 340 MHz/3.4Gbps per channel (10.2Gbps all channel)
• USB standard: USB2.0 compatible (up to Full Speed mode [Standard value]). High Speed mode is not supported.)
• device-to-device control (CEC): supporting
• PASS Through
• *It may not operate dep***ing on the connected device or function.
• Supported audio formats: LPCM
• Power Consumption: Transmitter/2.87 W
• Receiver/5.37 W
• HDCP: support
• *The display must also support HDCP.
• LAN port standards: IEEE 802.3 (10BASE-T Ethernet), IEEE 802.3u (100BASE-TX Fast Ethernet)
• Environmental conditions: Operating: 0~50°C Humidity: 80% or less (non-condensing)
• Storage: -20~60°C Humidity: 85% or less (non-condensing)
• Size: Transmitter: W182 x D121.9 x H28.7mm
• Receiver: W182 x D121.9 x H28.7mm
• Weight: Transmitter/about 630 g
• Receiver: Approx. 650 g
• Set Contents: Transmitter x 1, Receiver x 1, AC Adapter (DC5 V/2.6 A) x 2, Cable Set for PC (1.8 m) x 1, Rack Mounting Plate x 2, Plate Mounting Screws x 4, Rubber Feet x 8, Ground Wire x 2, Owner's Manual (with warranty) x 1
• [Support Information]
• Compatible device: Computer equipped with a USB (A connector female) or HDMI output terminal as standard
• Supported consoles: TV and PC displays equipped with an HDMI input terminal as standard
• USB keyboard, USB mo***
