Features

• Similar to 1S4, the current is slightly larger.
• Package: Axial
• VRRM: 40 V
• IF (RMS): 1.57 A
• IFSM: 40 A
• Tjw: -40°C~+150°C
• Tstg: -40°C~+150°C
• IRM (MAX): 1.0 mA
• VFM (MAX): 0.55 V
• Rth (j-a): 140°C/W
• Notes: Thermal resistance without single fin
• [Recomm***ed point]
• For switching: Suitable for switching converters with low peak reverse current.
• 【 Features 】
• Low forward voltage: Vfm=0.55 V (Tj=25°C Ifm=1 A)
