65-4307-71-20 Differential Pressure Meter 100 Pa with Inspection Certificate DG85-39B
Product Description
Product Model: 65-4307-71-20Product Brand: NAGANO KEIKI […]
Contact Us
Product Details
Product Model: 65-4307-71-20
Product Brand: NAGANO KEIKI Co., Ltd.
Features
- This instrument is mainly ***d to detect differential pressure due to pressure loss in air filters for air conditioning, and can be ***d for very low pressure measurement. A high-precision differential pressure meter that can be ***d as a fine differential pressure meter, as well as a flowmeter and a fine pressure meter.
- Comes with 2 installation needles.
Spec
- Size (mm): Φ85
- shape (mounting): wall-mounted
- connections: outside diameter Φ7 bamboo joints
- Materials: silicone rubber, polyacetal resin, methacrylic resin, aluminum alloy, phosphor bronze, brass, neoprene, NBR
- Pressure Range: Pa_0~100
- Accuracy: ±2.5%F.S.
- Treatment: Pear
