65-4306-64-20 Differential Pressure Meter 1000 Pa with Inspection Certificate DG70-391
Product Description
Product Model: 65-4306-64-20Product Brand: NAGANO KEIKI […]
Contact Us
Product Details
Product Model: 65-4306-64-20
Product Brand: NAGANO KEIKI Co., Ltd.
Features
- This instrument is mainly suitable for differential pressure detection due to pressure loss of air filters for air conditioning, and can be ***d for very low pressure measurement.
- For semiconductor clean room control, this product is available as a digital differential pressure meter, differential pressure sensor, and small differential pressure meter in the differential pressure meter series.
- A compact differential pressure meter that can also be ***d as a flow meter and a fine pressure meter.
Spec
- Size (mm): Φ70
- shape (mounting): wall-mounted
- Connections: Outer Diameter φ7 Bamboo Joints
- Material: Silicone rubber, NBR, polycarbonate resin, aluminum alloy, phosphor bronze, brass, NBR
- Pressure Range: Pa_0~1000
- Accuracy: ±2.5%F.S.
- Treatment: Pear
