65-4306-58-20 Small Pressure Gauge 0.15 MPa with Inspection Certificate DG12-121
Product Description
Product Model: 65-4306-58-20Product Brand: NAGANO KEIKI […]
Contact Us
Product Details
Product Model: 65-4306-58-20
Product Brand: NAGANO KEIKI Co., Ltd.
Features
- This instrument is a case closed system, and the high pressure side (H) is introduced into the Bourdon tube and the low pressure side (L) is introduced into the case, and the differential pressure is detected by the change of the Bourdon tube. It is a small pressure differential.
Spec
- Size (mm): Φ70
- shape (mounting): vertical
- Connection: R1/4 (H side), Rc1/4 (L side)
- Material: Copper Alloy, Aluminum Alloy, Zinc Alloy, Inorganic Glass, NBR
- Pressure Range: MPa_0~0.15
- Accuracy: ±3.0%F.S.
- Treatment: Pear
