65-4289-66 Normal Pressure Gauge (Φ100) Vertical C Frame for Vibration Resistance -0.1~0.25 MPa AE20-841
Product Description
Product Model: 65-4289-66Product Brand: NAGANO KEIKI Co […]
Contact Us
Product Details
Product Model: 65-4289-66
Product Brand: NAGANO KEIKI Co., Ltd.
Features
- A pressure gauge with a structure that transmits the elastic deformation (movement) of the Bourdon tube to a pointer. The simple structure makes handling easy. It can measure a wide pressure range and is ***d in a wide range of fields.
Spec
- Size (mm): Φ100
- Shape (Mounting): Vertical C Frame
- Connections: G1/2B
- Material: Brass
- Performance: For Vibration Resistance
- Pressure Range: MPa_-0.1~0.25
- Accuracy: ±1.5%F.S.
- Treatment: Pear
- Class: 0
