Spec

• Printing Method: Thermal Transfer Method
• Resolution (dpi): 300
• printing speed
• Tube: High speed mode 25 mm/sec, Standard mode 18.5 mm/sec, Low speed mode 12.5 mm/sec
• Label: High speed mode 25 mm/sec, Standard/Low speed mode 18.5 mm/sec
• Processing speed: High-speed mode approx. 35/min, Standard mode approx. 30/min, Low-speed mode approx. 21/min
• Printing Conditions: Tube Print Cut Length 20 mm, 5 Characters (3 mm Full Width) Print, With Half Cut, Standard Cut Strength
• ink ribbon
• Ribbon IC Cassette (Black, White)
• Length (Black: 40 m, 100 m, White: 85 m)
• Print Character Size: 2 mm (Kanji cannot be printed), 3 mm, 6 mm (Full-width/Half-width available)
• Character type: JIS 1st level, JIS 2nd level, symbols
• Input method
• Rubber keyboard
• Romaji/Kana conversion * 1 input, Hiragana input
• Alphanumeric character input, kuten code input, symbol input
• Number of dictionaries (approx.): 5,000 words
• Display method: 160 x 64 dots graphic display by liquid crystal display
• Number of characters to be displayed: Input data 10 characters ×2 lines (full-pitch) or 20 characters ×2 lines (half-pitch)
• Memory:
• Print character data storage: Approximately 2,500 characters * 2
• File storage: Approximately 7,500 characters # 2
• Folder hierarchy: None
• Cut Method: Automatic Half Cut, Automatic Full Cut
• Power: AC Adapter (100 VAC ~240 VAC 50/60Hz)
• Operating environment
• Temperature/15°C~32.5°C, Humidity/10%~85%
• Can be ***d even at low temperatures of 5°C to 18°C by attaching a tube warmer (optional)
• Maximum power consumption: 12.5 W
• Storage Environment: Temperature: 5°C~35°C, Humidity: 10%~90%
• Body Dimensions: Width (W) 250 x Depth (D) 300 x Height (H) 85
• Body mass (kg): 2
• printing member
• Tube: Commercially available PVC round tube * 3 (Inner diameter: ∅2.5 mm~5.2 mm compatible thickness: 0.5 mm)
• Label Tape: Cassette (White, yellow, and silver) Width: 6 mm, 9 mm, 12 mm Length: 30 m (Silver 27 m) Cut Length Setting: 8 mm to 150 mm Can be set * 4
• Wrap-Around Tape: Cassette (Print Portion Only, White, Other, Transparent) Winding Length: 8 m, Length: 33 mm, Width: Can be set to 8 mm to 150 mm by setting the cut length
• 4 mmID Strip: Cassette (White) Width: 4 mm, Length: 5 m, Cut Length Setting: 8 mm~ 150 mm Configurable
• Included items: Main unit, AC adaptor, AC power cable, tube attachment, Ribbon IC cassette black (40 m), Owner's Manual (CD-ROM), Request registration of the purchased product's warranty
• *1 Single Kanji conversion only.
• *2 Built-in battery lasts more than 5 years.
• *3 When other tubes (Inner Diameter: ∅ Other than 2.5 mm to 6.5 mm, Thickness: Other than 0.5 mm) are ***d, a print test and tube cut test are required in advance.
• *4 When the cut length is less than 3 mm and 1.3 mm full-pitch or 2 mm half-pitch, there may be a break in the characters. When cutting in half with a cut length of 3.5 mm or less, *** label tape of 9 mm or 12 mm width and adjust the cut depth.
