Spec

• Generation target gas permeation tube method: Gas sold as permeation tube
• Diffusion tube method: A stable, high-purity material having a vapour pressure in the range 5-400 mm Hg at a temperature in the set range of PD-1C as a characteristic of the liquid.
• Dilution gas type Nitrogen or air
• Dilution gas pressure: 0.15-0.6 MPa
• Flow setting range: 0.2-10 L/min
• Flow setting accuracy
• 0.2-0.4L/min:±13.2%s.p.
• 0.4-1L/min:±7.0%s.p.
• 1-10L/min±3.7%s.p.
• Temperature setting range: (room temperature +5°C)-50°C (room temperature is 15-30°C)
• Temperature setting accuracy: ±0.15°C
• Tube holder capacity
• Permeation Tube: Standard Size 10, H Size 5 (Permeation tube having H in catalog No. and P-17-5)
• Diffusion Tube: 1 for Single Component, 4 for Multiple Components
• Power Supply/Maximum Power Consumption: 100-240 V AC 50/60Hz 160 W
• Dimensions: 250 (W) x 340 (H) x 315 (D) mm
• Weight: approx. 14 kg (without water)
• Accessories: 2 Calibration Gas Tubes (Teflon Tube Outer Diameter φ6 x Inner Diameter φ4 mm2 m), 1 Dilution Gas Tube (With Dust-Proof Filter) (Outer Diameter φ6 x Inner Diameter φ4 mm2 m), 1 Power Cord (2 m), 1 Power Conversion Adapter, 1 Rubber Plug, 1 Tube Holding Basket
• Compliance Planning Constant Voltage Directive: EN61010-1 EMC Directive: EN61326-1 (For *** in industrial locations)
