Spec

• Measurement range (when using PV-57 I): ACC (acceleration)/0.02~200 m/s^2 EQ PEAK 1~5 Hz, VEL (speed)/0.3~1000 mm/s RMS 3 Hz~1 kHz, 0.1~1000 mm/s RMS 10 Hz~1 kHz, DISP (displacement)/0.2~100 mm EQ PEAK 3~500 Hz, 0.001~100 mm EQ PEAK 10~500 Hz
• Frequency Range: ACC (acceleration)/3 Hz - 1 kHz/3 Hz - 5 kHz/1~100 Hz/3 Hz - 20 kHz, VEL (speed)/10 Hz - 1 kHz/3 Hz - 1 kHz, DISP (displacement)/10~500 Hz/3~500 Hz
• Measurement Range: Pickup PV-57I and Pickup Sensitivity/1.0~9.9 mV/m/s^2, ACC (Acceleration)/1/10/100/1000 m/s^2, VEL (Speed)/10/100/1000 mm/s, DISP (Displacement)/0.1/1/10/100 mm
• Indicative characteristics: Acceleration/RMS/EQ PEAK, Velocity/RMS/EQ PEAK, Displacement/RMS/EQ PEAK/EQ p-p
• LCD (monochrome segment LCD)
• Backlight: White LED (blinking red LED when OVER)
• Measurement value display: display range 001~128 (100 ms sampling 20 arithmetic averages displayed every 2 seconds)
• Bar chart: 1~100% full scale logarithmic scale
• Indicative characteristics: RMS, EQ PEAK, EQ p-p
• Overload display: display OVER text (blinking red LED at the same time)
• Measurement Mode: Acceleration, Velocity and Displacement
• Memory addresses: 000~999 (1000)
• Battery level indicator: 4 levels
• Clock display: Year, Month, Day, Hour, Minute
• Pickup sensitivity: 0.10~0.99, 1.0~9.9, 10~99 mV/m/s^2
• Data Memory: Up to 1000 (000~999) data can be stored manually
• Calibration of amplification degree: Amplification degree commensurate with each sensitivity by setting the pickup sensitivity
• Measurement range: 0.10~0.99, 1.0~9.9, 10~99 mV/m/s^2(pC/m/s^2 with VP-40/42)
• AC/DC Output: Range Full Scale/1 V, Output Impedance/Approx. 600 Ω
• Output Voltage and Display Accuracy (Body Electrical Characteristics): ACC (Acceleration)/Range Full Scale ±2% (80 Hz), VEL (Velocity)/Range Full Scale ±3% (80 Hz), DISP (Displacement)/Range Full Scale ±5% (80 Hz)
• Overall accuracy (when combined with PV-57 I): ACC (acceleration)/Range Full Scale ±5% (80 Hz), VEL (velocity)/Range Full Scale ±8% (80 Hz), DISP (displacement)/Range Full Scale ±10% (80 Hz)
• Intern face: USB (for data output and serious remote control. Data capture using dedicated transfer software
• Operating Temperature and Humidity Range: Pickup/-20~70°C, 90%RH or Less, Body/-10~50°C, 90%RH or Less
• Power supply: 4 AA batteries (alkaline/nickel-metal hydride) or AC adapter (NC-98E, optional)
• Battery life: Alkaline battery/approx. 30 hours (Normal temperature, backlight OFF, each output and communication OFF), Ni-MH battery (eneloop pro®)/approx. 32 hours (Normal temperature, backlight OFF, each output and communication OFF)
• Size: approx. 171.5 x 74 x 25.5 mm
• Weight: approx. 270 g (including battery)
• Accessories: Piezoelectric Acceleration Pickup x 1, AA Battery (Alkaline) LR6 x 4, Pickup Curl Cord VP-51KI x 1, Magnet Attachment VP-53S x 1
