Electronic/Electrical Parts and Controll Equipments
63-4716-91 Vishay 22μF 63V dc Aluminium Electrolytic Capacitor, Through Hole 6.5 (Dia.) x 18mm +85°C 6.5mm 25mm MAL203138229E3
Product Description
Product Model: 63-4716-91Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-4716-91
Product Brand: Vishay
Features
- NFC 93110, CEI 384-4. 031 AS Series. Miniature axial electrolytic capacitors offering high CV values For coupling, decoupling, smoothing, filtering, buffering and timing functions Applications include: audio and video circuit connections, measuring, regulation. Life expectancy 2000 hours
Spec
- Quantity：1bag(5pieces)
- Capacitance : 22µF
- Voltage : 63V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 6.5 (Dia.) x 18mm
- Height : 18mm
- Minimum Operating Temperature : -40°C
- Diameter : 6.5mm
- Maximum Operating Temperature : +85°C
- Lifetime : 2000 h, 3000 h, 80000 h
- Series : 031 AS
- Leakage Current : 7.8 μA, 13 μA
- CODE No.:180-1797
