63-4713-14 1.9 V, 2.2 V Green & Red LED 5mm Through Hole, Broadcom HLMP-4000 HLMP-4000
Product Description
Product Model: 63-4713-14Product Brand: Broadcom Featur […]
Contact Us
Product Details
Product Model: 63-4713-14
Product Brand: Broadcom
Features
- Avago HLMP-40xx and HLMP-08xx Series LEDs. The HLMP-40xx and HLMP-08xx series, from Avago Technologies, are rectangular bi-colour LED lamps. The HLMP-40xx come in a T-1 3/4 package and the HLMP-08xx are in a 2 x 5mm rectangular package. These LEDs are three leaded bi-colour light sources which are suitable for a variety of applications where dual state illumination is required in the same package. They contain two LED chips which are mounted on a central common cathode lead. This allows for maximum on-axis viewability. Colours between the chips can be generated by indep***antly pulse width modulating the LED chips.. Features of the HLMP-40xx and HLMP-08xx LEDs: - Two colour operation - Three leads with one common cathode
Spec
- Quantity：1bag(5pieces)
- LED Colours : Green, Red
- Package Type : 5mm (T-1 3/4)
- Mounting Type : Through Hole
- Number of LEDs : 2
- Forward Voltage : 1.9 V, 2.2 V
- Luminous Intensity : 2.1 mcd, 4.2 mcd
- Number of Pins : 3
- Viewing Angle : 65 °
- Lens Shape : Round
- Dominant Wavelength : 570 / 626 nm
- Dimensions : 5 x 9.19mm
- Lens Colour : Clear
- CODE No.:171-2136
