1-9015-11 Stainless Steel Desiccator 574 x 524 x 1770mm SP-SSUSFN
Product Description
Product Model: 1-9015-11Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 1-9015-11
Product Brand: AS ONE Corporation
Features
- Suitable for static electricity protection and chemical storage of electronic components.
- A new type of solid polymer electrolyte membrane (Rosal ®) is installed on the front panel to directly electrolyse and continuously remove moisture from the interior air.
- By adopting a new type of door opening and closing mechanism and eliminating dead space when opening and closing the door, it can be installed without clearance on the wall surface.
- The door part ***s magnet packing with excellent airtightness, and the door opens and closes smoothly.
- Highly effective against static electricity.
Spec
- Auto Dry Type
- Dehumidification system: H2O electrolysis emission by a solid polymer electrolyte membrane
- Humidity setting range: 20 to 50 %RH
- Humidity control system: Automatic dial adjustment (relative humidity)
- Humidity control range: approx. 25 %RH to room humidity (In environment ***d at the time of unload)
- Material: Main body / stainless steel (SUS304), door / antistatic PMMA (acrylic) plate, frame / aluminum sash, shelf board / stainless (SUS430)
- The lower right side of the main body is equipped with a ground terminal 1 location (With 3m ground wire)
- shelf board Dimensions: 490 x 460 mm
- shelf board installed pitch: 50 mm
- shelf board interval : 40 mm
- shelf board Load tolerance: about 20 kg / sheet
- Custer: φ 65 mm nylon (front wheel with stopper)
- power supply: AC100V 50 / 60Hz
- power cord: 3P plug approx. 2 m
- Average Power Consumption: 5W
- Weight: Main (Excluding shelf board) / 40 kg, shelf board / 1.5 kg / sheet
- Accessories: shelf board / 4 pieces, High Precision Digital thermo-hygrometer (THI-HP)
- Model number: SP-SSUSFN
- external dimension (mm): 574 x 524 x 1770
- inner size (mm): 560 x 483 x 1486
*This product might require extra fees.
