gasmonitors
3-5861-01 Etching ChAmber 2 Tank Type PVC Standard Type 1200 x 820/750 x 2150 PS-1200II
model:
3-5861-01
category:
gasmonitors
Product Description
Product Model: 3-5861-01 Features A draft chamber suita […]
Contact Us
Product Details
Product Model: 3-5861-01
Features
- A draft chamber suitable for *** in etching and cleaning processes in semiconductor manufacturing processes.
- Made of rigid PVC (vinyl chloride resin) with excellent acid and alkaline resistance, it can be conveniently ***d for work using acid treatment or other chemicals.
- Since it is a 2-tank type, you can *** it conveniently according to your application.
Spec
- Exterior, interior: Hard PVC (vinyl chloride resin)
- Sink unit: Hard PVC (vinyl chloride resin)
- Window: Transparent hard PVC (vinyl chloride resin)
- Supply water plug: Gooseneck type universal water plug for pure water
- Lighting devices: Using fluorescent lamps, with switch
-
- Surface speed (m/s) 350mm opening: 0.5
- Air volume (m3/min): 12
- Connection port (φmm): 200
- Duct diameter (φmm): 200
-
- Feed drainage: 2
- Fluorescent lamps (volume): 20W x 2
- Outlet AC 100V 15A double x 1 pieces included
- Outer dimension (mm): 1200 x 820/750 x 2150
- Inner dimension (mm): 1100 x 670 x 1100
- Weight (kg): 171
- Model number: PS-1200II
- *Transportation cost, carrying cost, installation cost, assembly cost, etc. are required separately. Please contact with us.
