Spec

• Size: 210 x 88 x 230 mm
• Weight: 3 kg
• Accessories: Power Cord (With 2-Wire Replacement Plug) x 1, F*** (2A Mini F***) x 1, Analog Output Cord x 1, Communication Cable x 1, Personal Computer Software AMS-800 x 1 Owner's Manual x 1
• Number of input points: 1
• Measurement range (°C): -195.0~450.0
• Resolution (°C): 0.1
• Accuracy (when calibrated): ±0.5°C (within ±50°C calibration temperature)
• Temperature coefficient: +/- (0.01% of F.S./°C) except at an ambient temperature of 25°C +/- 5°C.
• Operating environment: Temperature ...0~40°C, Humidity ...15~80%RH (non-condensing)
• Storage environment: Temperature ...-10~50°C, Humidity ...10~80%RH (non-condensing)
• Display: 15 mm Text Height Red LED
• Refresh: 1 second
• Light Source: Blue LED
• Power: 100 VAC ±10%, 50/60Hz AA Alkaline Batteries x 6
• Power consumption (VA): 12
• Memory capacity: 15000 data, 1 second interval
• Interface: RS-232C transfer rate ...9600bps, data structure ...7bit length, odd parity, 1stop bit
• Calibration: 1-point calibration Actual temperature calibration at an arbitrary temperature within the measurement range
• Analog output/output rate: 10 mV/°C
• Analog power/resolution (mV): 1
• Analog output/accuracy: ±(0.2% of F.S.) Ambient temperature: Within 25°C±5°C
• Analog power/temperature coefficient: ±(0.01% of F.S./°C)
