65-3529-57 Built-in Temperature Sensor for Moving Rotating Surface UH Series -50~210°C E Type Type 11 UH-11E-03-TS1-W
Product Description
Product Model: 65-3529-57Product Brand: ANRITSU METER C […]
Contact Us
Product Details
Product Model: 65-3529-57
Product Brand: ANRITSU METER CO., LTD.
Features
- The UH series is a built-in temperature sensor for moving and rotating surfaces suitable for measuring the surface temperature of rollers in narrow areas.
- [Application] Surface temperature control and temperature measurement of printer roller, etc.
Spec
- Operating temperature range (°C): -50~210
- Tolerance at 0~100 deg. C (deg. C): ±2.5
- Response Time (sec): 4
- Fixing plate shape: Type 11
- Thermocouple Type: E Type
- Length of connecting wire (mm): 300
- Cord length (m): 1
- Cord Outer Diameter (φmm): 2.3
- Coating Material: Silicon
- Heat-resistant Temperature (°C): 240
- Plug Shape: Off
