Spec

• Convection system: Forced convection system
• Performance:
• Temperature adjustment range (accuracy): - 15 ~ 85 degrees C (+/- 0.5 degrees C)
• Humidity adjustment range (accuracy): 25 ~ 98% RH (+/- 3% RH)
• Temperature and humidity distribution accuracy: within +/- 2 degrees C and +/- 6% RH
• Features:
• Temperature and humidity control system: P.I.D control
• Dehumidification system: Normal operation: Automatic control (interval defrost mode) Forced manual operation (Manual Start, Automatic Stop, Manual Stop)
• External input/output: RS -232 C connection jack Temperature/humidity recorder output jack (Temperature 1 deg C/mV, Humidity 1% RH/mV) Output: - 200 ~ 200 mV alarm output jack (Contactless/Voltage-free, Contact Capacity AC 250 V 5 A Normally OFF, Abnormal ON)
• Other functions: Calibration of temperature and humidity display, external water supply, maintenance mode, forced drainage
• Configuration:
• Interior: SUS 304
• Heaters: Heating heater 650 W, Humidifying heater 200 W x 2
• Refrigerator/Refrigerant: Air-cooled output: 200 W/R 134 a
• Interior Dimensions (mm)/Capacity: 500 W x 400 D x 700 H/140 L
• Shelf Board Load Capacity, Material, Number of Stacks: Uniform Distribution Max. 15 kg/Sheet, SUS 304/10 Stacks
• Number of Shelf Boards Attached/Shelf Pitch: 2/40 mm
• Cable hole: 1 (right side of main body) 40 mm inside diameter
• Water tank capacity/internal: approx. 10 L (removable from front), external: approx. 20 L (one-touch socket connection)
• Door packing material: Silicon
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (mm): 635 (800) W x 777 D x 1695 H (including trestle), 600 (800) W x 777 D x 1285 H (product body)
• Mass: About 145 kg
• Power input/voltage: 15 A, 1.5 kVA/100 VAC 50/60 Hz
• *Minimum and maximum attainable temperature, temperature and humidity adjustment accuracy, and temperature and humidity distribution accuracy dep*** on operating conditions such as room temperature, heat load conditions, and power supply voltage.
• *During defrosting operation, the internal temperature rises by -2 to + 2 degrees Celsius, approximately 3 degrees Celsius, and the internal humidity rises by approximately 30% RH. The amount of change dep***s on the operating conditions.
• *At room temperature of 35 degrees Celsius, the minimum attainable temperature is -10 degrees Celsius.
• *Dimensions in brackets () include projections.
• Accessories: 1 external water supply tank (20 L), 1 tank rack, 1 water supply and drainage hose (1 m each), 1 silicone plug for cable hole, 1 alarm output connector, 1 RS -232 C communication cable, 1 communication software ESmon, etc.
• Code: 204580
