65-0573-91 Thermostat Soft Incubator Approx. 78 L SLI-400
Product Description
Product Model: 65-0573-91Product Brand: TOKYO RIKAKIKAI […]
Contact Us
Product Details
Product Model: 65-0573-91
Product Brand: TOKYO RIKAKIKAI CO., LTD.
Features
- Basic type thermostat for E. coli and microorganism culture
- Stable temperature control with air jacket system
- Since the air jacket system is a natural convection system, temperature distribution accuracy is excellent and stable temperature control with little sudden temperature change can be achieved. It is suitable for microbial culture that dislikes wind.
- You can also culture with a shaker at the service outlet in the cabinet. (An optional shaker shelf is required.)
- Optionally, you can retrofit the thermometer output terminal.
- Timer function (Auto Start, Auto Stop) is installed.
- In the event of a power failure during timer operation, you can select the operation of the device after the power failure returns. (Timer continuation from the state before the power failure, reset to the default time, restart, and stop operation)
- When a problem occurs as a safety function, an alarm display and an alarm buzzer are ***d to notify you.
- SLI-400 models can be stacked on top of each other and *** the installation space effectively.
Spec
- Convection system: Air-jacketed natural convection system
- Performance:
- Temperature adjustment range: room temperature + 5 ~ 60 degrees C
- Temperature control accuracy: +/- 0.1 degrees C (37 degrees C setting)
- Temperature distribution accuracy: +/- 2.5 degrees C (37 degrees C setting)
- Temperature distribution (at 37 deg. C): Spatial temperature deviation of 0.6 deg. C, temperature gradient of 0.7 deg. C
- Timer time range: 0 ~ 99 hours 59 minutes
- Features:
- Temperature Control/Setting/Display: P.I.D Control SSR Output/Sheet Key Input/Digital Display (Temperature display correction, auto start, auto stop 1 and 2, power outage recovery setting)
- Safety features: Alarm function (Upper temperature, open door, sensor, power failure, temperature uncontrollable, watchdog), indep***ent overrise protection (variable 30 ~ 70 degree Celsius), leakage/overcurrent breaker, f*** (for service outlet)
- Configuration:
- Heater: 280 W
- Temperature sensor: thermistor
- Standard:
- Interior and Interior Doors: SUS 304/-
- Interior Dimensions (mm)/Capacity: 434 W x 400 D x 450 H/Approximately 78 L
- Shelf Board Load Capacity, Material: Equal Distribution Max. 15 kg/sheet, PE Coating
- Number of Shelf Boards Attached, Shelf Pitch, Number of Racks: 2, 30 mm, 8 Racks
- Service outlet: 1 (Interior Max. 2A)
- Operating ambient temperature range: 5 ~ 35 degrees C
- External dimensions (mm), Mass: 526 (553) W x 550 D x 800 H, approx. 41 kg
- Power input/voltage: 3 A, 300 VA/AC 100 V 50/60 Hz
- *Performance is measured at room temperature of 25 degrees Celsius, rated supply voltage, 50 Hz and no load.
- *Due to the nature of the product, there may be a difference between the set temperature and the measured temperature.
- *When a shaker is placed in the chamber, the temperature adjustment range is above + 10 degrees Celsius. Also, the internal temperature may fluctuate.
- *Performance notation for temperature distribution conforms to JIS C 60068 -3 -5 JTM K 07 -2007 (Performance test method and performance display method of temperature test tank, Japan Testing Machine Industry Association).
- *Dimensions in parentheses include projections. *Power input does not include internal outlet capacity.
- Code: 197180
