Spec

• Trapping system: Can body cooling system (Glass trap: optional, direct trap)
• Performance:
• Dehumidification capacity: Max. 1 kg (water system)
• Minimum temperature reached: -45 degrees C
• Features:
• Display and display resolution: Trap temperature display (digital display), 5 degrees C
• Safety functions: Leakage/overcurrent breaker, high-pressure switch (refrigeration cycle), refrigerator overload relay, self-diagnostic function (Refrigerator malfunction, power failure alarm, sensor malfunction)
• Accessory functions: trap temperature display, defrost function, vacuum pump operation switch (vacuum pump control output), ***r adjustment mode (Display temperature correction and blackout recovery settings), trap tank saturation detection function (optional)
• Configuration:
• Refrigerator: Air-cooled output: 450 W
• Refrigerant: HFC R 452 A
• Trap Tank Material: SUS 304
• Temperature sensor: T thermocouple
• Standard:
• Inner Tank Dimensions (mm)/Capacity: Inner Diameter 153 x 225 H/About 3.9 L
• Connection diameter: 17.3 mm for both intake and exhaust
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (mm): 300 (335) W x 350 (362) D x 835 (1009) H
• Mass: About 33 kg
• Power input/voltage: 7 A, 700 VA/AC 100 V 50/60 Hz
• *Performance is measured at an ambient temperature of 20 degrees Celsius and a rated supply voltage of 50 Hz. The minimum temperature reached indicates the temperature of the can wall inside the tank.
• *Indicates the nozzle diameter of the trap tank lid.
• *Dimensions in parentheses include projections.
• Code: 279980
