Spec

• Performance:
• Temperature control range: room temperature + 10 ~ 200 degrees C (-30 to room temperature + 10 degrees C when using the chiller)
• Temperature control accuracy: +/- 0.03 degrees C to +/- 0.1 degrees C
• Temperature gradient: less than 1 degree C/min when rising
• External Circulation Capacity: Maximum Discharge 6.7 L/min, Maximum Pump Head 2.9 m (50 Hz, water)
• Features:
• Temperature control: P.I.D control and SSR output
• Temperature setting/display: Numeric keypad input, minimum setting digit 0.01 degrees C, digital display
• Program functions: 1. Constant value operation (normal mode) 2. Auto start 3. Auto stop (1 minute to 99 hours and 59 minutes) 4. User program 3 patterns (1 pattern: Max. 10 segments, 1 minute to 99 hours 59 minutes/1 segment)
• Safety functions: Self-diagnostic function (Low water level, sensor error, SSR failure, overheating, heater break, power failure alarm, program gradient failure), leakage/overcurrent breaker
• External input/output: RS -232 C connection terminal, external temperature sensor terminal
• Configuration:
• Heater: 1.2 kW (SUS 316 L) for both water and oil
• Stirring in tank: jet type, maximum discharge 10 L/min, maximum head 3 m (50 Hz)
• Temperature sensor: Platinum temperature resistor Pt 100 ohm
• Standard:
• External Circulation Nozzle (Sealed System Directional Circulation)/Discharge Port: Outer Diameter 10 mm Hose Port (Rc 1/4 with stop valve), Return Port: Outer Diameter 10 mm (Rc 1/4)
• Cooling nozzle: inlet and outlet, both outer diameters 10 mm, hose mouth
• Water tank material: SUS 430 J 1 L
• Inside tank (effective) dimensions mm, capacity: 250 W x 295 D x 180 H (250 x 150 x 180), 13 L
• Operating ambient temperature range: 5 ~ 35 degrees C
• External Dimensions (mm)/Mass: 310 W x 405 (465) D x 389 H/17 kg
• Power input/voltage: 13 A, 1.3 kVA/100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz and no load.
• *Use silicone oil when using above 80 degrees Celsius.
• *Use a stainless steel flexible tube (screw-standard tapered O-screw R 1/4: commercially available) when circulating fluid above 80 degrees Celsius outside the tank.
• *Dimensions in parentheses include projections.
• Code: 113610
