Spec

• Method: Natural Convection Type
• Operating Environment Temperature Range: 5~35°C
• performance and configuration
• Temperature Control Range: (Room Temperature +5) ~110°C
• Exterior: Chromium-Free Electrogalvanized Steel Plate Baked Coating
• Interior: Stainless Steel Plate
• Insulation: Glass wool
• Observation window: Tempered glass double structure Width 300 x Height 800 mm
• Heater: Stainless Steel Pipe Heater 1200 W
• Exhaust Port: Inner Diameter φ30 mm x 2 (Ceiling Surface) With Lid (Opening Ratio When Closed 20%)
• Controller
• Temperature Control System: P.I.D. Control
• Temperature Setting Method: ▲ ▼ Digital setting system by key
• Operation Mode: Constant Value Operation, Quick Auto Stop Operation, Auto Stop Operation, Auto Start Operation
• Timer: 1 minute ~99 hours 59 minutes/Every 1 minute, 100 hours 00 minutes ~999 hours 50 minutes/Every 10 minutes
• Sensor: K Thermocouple (Temperature Control)
• Other functions: Calibration offset function, set value lock function, power failure recovery mode selection function
• Safety device: self-diagnostic function (Automatic Excess Temperature Rise Prevention, Temperature Sensor Abnormality, Memory Abnormality), maintenance function (Leakage Breaker, Indep***ent Excess Rise Prevention Device)
• Standard
• Internal volume: 445 L
• Number of Shelf Support Steps/Shelf Support Pitch: 29 Steps/30 mm
• Shelf Board Size: Width 594 x Depth 556 mm
• Shelf Plate Load Capacity: 15 kg/Sheet (Total Load Capacity: 60 kg)
• Inner Dimensions (Width x Depth x Height): 620 x 600 x 1195 mm
• Remarks (Dimensions): Effective Inner Dimensions: Width 600 x Depth 600 x Height 1117 mm
• External Dimensions (Width x Depth x Height): 698 x 710 x 1615 mm
• Power Capacity: 100 VAC 13 A, Breaker Capacity and 15 A Supply Capacity
• Weight: 115 kg
• Accessory: 3 Shelf Plates/3 Shelf Bracket Sets (The bottom shelf is separately fixed in the tank.) , water receiving tray
