Spec

• Size (mm): 460 x 360 x 185
• Weight (kg): 11
• Wavelength range: 320 ~ 1100 nm
• Spectral bandwidth: 4 nm
• Wavelength accuracy: +/- 1 nm
• Wavelength reproducibility: 0.5 nm
• Measurement system: Single beam (1200 lines/mm)
• Measuring range: Transmittance/0 ~ 200% T, Absorbance/-0.3 to + 3 A, Concentration/0 ~ 1999 C
• Accuracy of measurement: Transmittance/+/- 0.5% T
• Stray: 0.05% T (@ 360 nm)
• Scan speed: up to 4200 nm/min
• Stability: 0.002 A/h (@ 500 nm)
• Cell holder: 4-cell holder
• Light source: Tungsten lamp
• Power supply: 100 VAC 50/60 Hz
• Accessories: 4 glass square cells
• Inspection contents App***ix: Inspection inspection documents
• Confirmation of baseline, wavelength accuracy and transmittance of 50%
• App***ix: Inspection Certificate documents
• *Products with Inspection Certificate are Azwan's original service that includes inspection of control and electric engine personnel and issuance of inspection documents at the time of shipment.
