Spec

• Convection system: Natural convection system
• Performance:
• Temperature adjustment range: room temperature + 10 ~ 80 degrees C
• Temperature control accuracy: +/- 1.5 degrees C (at 80 degrees C)
• Time to reach temperature: about 30 minutes (up to 80 degrees Celsius)
• Features:
• Temperature control system: microcomputer P.I.D control SSR output
• Temperature setting and display: Sheet key input and digital display
• Timer function: Auto Stop
• Safety features: Self-diagnostic function (Overheating, temperature sensor error, control error, ambient temperature error), indep***ent overrise detector, control circuit protective f***, key lock function, door opening, overcurrent/earth-leakage breaker
• Configuration:
• Heater: Stainless steel sheath heater 1.34 kW
• Standard:
• Interior Dimensions (mm)/Capacity: 610 W x 600 D x 1230 (1060) H/Approx. 458 L
• Shelf Plates Included: 3
• Shelf Pitch/Number of Racks: 30 mm/30 Racks
• Observation window: 300 W x 800 Hmm
• Interior: SUS 304
• Vent: 105 mm top center
• Door packing: Silicon
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (mm): 684 W x 730 D x 1615 H
• Mass: About 110 kg
• Power input/voltage: 13.4 A, 1.34 kVA/100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, 50 Hz, no load and with the exhaust port closed.
• Code: 271630
