Spec

• Setting range (°C): 0~500
• Sensor Type: K Thermocouple
• Temperature control system: PID control or ON/OFF control
• Temperature display accuracy: ±0.3% (FS) or ±3 deg. C, whichever is greater.
• Excessive temperature rise prevention setting: Absolute value upper limit setting (setting to set a specified value as a forced cut-off temperature) or deviation upper limit setting (setting to set a deviation value from the control temperature as a specified forced cut-off temperature)
• Alarm operation: Alarm operation retention (Automatic recovery does not occur after relay interruption.)
• Output Terminal: M4 Screw Terminal
• Connection Capacity: MAX7A (Resistive Load)
• Size: 138 x 159 x 94 mm
• Power: 220 VAC 50/60Hz
• K Thermocouple Specifications
• Stainless Steel Sheath Type (SUS304)
• Size: Φ3.2 mm x 200 mm
• Cable length: 1.9 m
• This part is sold for the maintenance of the product you have already purchased.
• *This product cannot be ***d for any other purpose.
• *We do not handle individual inquiries such as parts specifications.
• *Products repaired with purchased parts are not covered by the warranty.
• However, we guarantee the initial failure of purchased parts.
