Spec

• DC Voltage (V): 600
• AC voltage (V): 600
• DC current (A): 10
• Resistance (Ω): 20 M
• measurement item: DC voltage, AC voltage, DC current, resistance, continuity check, diode check, battery check
• Measurement range (* Maximum Accuracy): [DC Voltage] 200 m/2000 m/20/200/600 V * ± (0.5% rdg + 2 dgts), [AC Voltage] 200/600 V * ± (1.2% rdg + 3 dgts), [DC Current] 200 μm/200 m/10 A * ± (1.0% rdg + 2 dgts), [Resistance] 200/2000/20 k/200 k/20 M ohm * ± (0.8% rdg + 2 dgts)
• Diode Check: Measure Diode Forward Voltage
• Continuity check: Alarm (buzzer) sounds at approx. 10 ohm or less
• battery Check: 1.5 V/9 V/12 V
• Maximum input voltage: DCV 600 VDC/ACpeak, ACV 600 Vrms
• Maximum input current: 200 mA (μA/mA range), 10 A (10 A range)
• Input Impedance: Approximately 10 M ohms or more (DC voltage range)
• Sampling rate: 2 to 3 times/second
• F***: 0.2 A/250 V (φ 5 x 20 mm) Ceramic Quick Blow F*** 1 piece, 10 A/250 V (φ 5 x 20 mm) Ceramic Quick Blow F*** 1 piece
• Height (mm): 134
• Depth (mm): 47
• Power Supply: AAA size type battery 2 pieces
• Width (mm): 77
• Detection method: Average rectification (MEAN)
• Width x Depth x Height: 77 x 47 x 134 mm
• Power Supply: AAA size battery x 2 pieces (included for testing)
• Maximum display: 1999 counts
• Comprises: Test lead, battery (for monitor), protective cover and instruction manual.
• Weight: 206 g
• Country of Origin: China
• Securities Code: 240 -9214
